Vision Measuring Machine

Quantity:
Availability:





Inquire Add to Basket

Product Description

Product Features:

The automatic 3 D image measuring instrument is designed for plane and 3 D dimension measurement, and its maximum stroke reaches 400500mm, which is suitable for large stroke measurement in PCB, LCD, sheet metal, aerospace and other industries. It adopts the mobile bridge structure, gathers the most advanced design concept in the industry, with the most perfect design and the most strict production process control, to ensure the accuracy and stability of the machine.
CNC is a series of Gantry CNC video measuring machines , which are specially designed for large size measurement.The largest measurement range can reach 400× 500mm, and can be applied in the industries of PCB, LCD, sheet metal, civil aviation and space industries, etc.VMG integrates the industry's most advanced design concepts.The accuracy and stability of the machine can be ensured well on account of the most perfect design and strict controls during production.

Product Parameters

Automatic image measuring meter
model Model	route or distance of travel (mm) Range	External dimensions (mm) of the External Size	weight (kg) Weight	bearing (kg) Capacity
FC-CNC-5040	400×500×200	680×880×900	240	25
Accuracy resolution	1µm
certainty of measurement Accuracy	XY axle *
	(3+L/200)µm
	* L indicates the measured length, measured in millimeters L, the measured length in mm. * The mechanical accuracy of Z axis is closely related to the surface of the workpiece **Mechanical accuracy of Z.Accuracy of focus is surface dependent.
velocity Speed	XY axle		Z axle
	380mm/s		100mm/s
work environment Operating Environment	Temperature Temperature: 20ºC± 2ºC Temperature change of Temperature Variation: <2ºC / hr Humidity Humidity: 30~80%
	Vibration of Vibration:<0.002g, <15Hz
	Power: 200 ~ 240 Vac, 50 / 60Hz, single-phase single-phase, 700W
